LTS XCPOE-SW402G Pro-X, 6-Port Cloud Managed Switch with 4-Port PoE
Sale price
$142.50
Regular price
$185.00
The LPS1110-E PoE Injector/Extender/Repeater enhances network and power reach for PoE devices, delivering up to 30 W PoE output per port with support for IEEE 802.3af/at standards, automatic port power detection, and reliable power delivery over extended cable runs. It simplifies long-distance IP camera installations, improves network flexibility, features plug-and-play operation, and offers rugged construction for dependable performance.
Features
- 4 x Gigabit PoE ports
- 2 x Gigabit uplink ports (2 x RJ-45 ports)
- 60W PoE power budget
- IEEE802.3af, IEEE802.3at power supply standards.
- Easy-to-use web-based and Cloud-based management interface
- Extend PoE signal up to 820 ft./250m at 10Mbps
- 12Gbps switching capacity
Specifications
| Model | XCPOE-SW402G |
| General | |
| PoE Ports | 4 x 10/100/1000Mbps PoE/PoE+ ports |
| Uplink Ports | 2 x 2 x 10/100/1000Mbps RJ-45 ports |
| PoE Standards | IEEE802.3af; IEEE802.3at(PoE+) |
| Network Standards | IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab |
| PoE Ports Power | Ports 1-4 ≤ 30 W(PoE+) |
| Total Power Budget | 60W |
| PoE Pin Assignment | 1,2,4,5 (V+) ,3,6,7,8 (V-) |
| Performance | |
| Switching Capacity | 12 Gbps |
| Packet Forwarding Rate | 8.9 Mpps |
| MAC Table Capacity | 8000 |
| Packet Buffer Size | 4.1 Mbit |
| MTBF | 222.36 years |
| Feature | |
| Layer | Layer 2 |
| Port Configuration | Port rate configuration, flow control, and ports enabling |
| PoE Watchdog | Ports 1 to 4 auto detect and restart the cameras that do not respond. |
| Long Distance Transmission | Up to 820 ft./250m at 10Mbps on PoE ports |
| VLAN | Port based VLAN |
| VLAN Number | 32 |
| IEEE 802.3x Flow Control | Support |
| Storm Control | Storm control of unknown unicast, multicast and broadcast |
| Port Mirroring | Support |
| Port Isolation | Support |
| LLDP | Support |
| Port Isolation | Support |
| DHCP Function | DHCP Client |
| Physical & Environmental | |
| Power Supply | 53VDC, 1.226A, external power supply |
| Power Consumption in Idle | 2.5W |
| Power Consumption in Total | 65 W |
| Surge Protection | Power port: 4 kV/2 kV Telecom port: 8 kV |
| Operating Temperature | "10 °C to +55 °C(+14 °F to +131 °F) |
| Storage Temperature | "40 °C to +70 °C("40 °F to +158 °F) |
| Operating Humidity | 5%"95% (RH), non-condensing |
| Storage Humidity | 5%"95% (RH), non-condensing |
| Dimensions | 130 mm x 90 mm x 26 mm (5.11" x 3.54" x 1.02") (L" W x H) |
| Net Weight | 0.29 kg (0.64 lb) |
| Gross Weight | 0.94 kg (2.07 lb) |
| Shell | Metal material |
| Certifications | FCC: Part 15 Subpart B |
