LTS LTN8932-P16 Platinum Enterprise Level 32 Channel 16Ch PoE, 4K Ultra HD Display NVR 1.5U
Sale price
$960.36
Regular price
$1,315.00
Skip to product information
LTS LTN8932-P16 Platinum Enterprise Level 32 Channel 16Ch PoE, 4K Ultra HD Display NVR 1.5U
Sale price
$960.36
Regular price
$1,315.00
- 32 Channel Network Video Recorder
- Support Live View, Storage, Playback up to 12MP IP Camera
- Quad-core CPU
- 256MB Bandwidth
- 16 Built-in PoE
- 4K (3840x2160) HDMI Video Output
- 4 SATA up to 8TB each HDD
- H.264/H.264 Zip+/H.265 Ready
| Model | LTN8932-P16 | |
| Recorder Series | Platinum Series | |
| Recorder Channel | 32-Channel | |
| Recorder Case | 1.5U Case | |
| Recorder Technology | IP / NVR | |
| Featured Product | No | |
| Video/Audio Input | ||
| IP Video Input | 32-CH, Up to 12MP Resolution | |
| Two-Way Audio Input | 1-CH, RCA (2.0 Vp-p, 1kΩ) | |
| Network | ||
| Incoming Bandwidth | 160Mbps | |
| Outgoing Bandwidth | 256Mbps | |
| Remote Connection | 128 | |
| Video/Audio Output | ||
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF | |
| HDMI Output | 4K (3840 2160)/60Hz, 4K (3840 2160)/30Hz, 1920 1080p/60Hz, 1600 1200/60Hz, 1280 1024/60Hz, 1280 720/60Hz, 1024 768/60Hz | |
| VGA Output | 1-ch, resolution: 1920 1080p/60Hz, 1280 1024/60Hz, 1280 720/60Hz, 1024 768/60Hz | |
| Audio Output | 1-CH, RCA (Linear, 1kΩ) | |
| Decoding | ||
| Live View/ Playback Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF | |
| Synchronous Playback | 16-CH | |
| Capability | 4-ch @ 4K, or 16-ch @1080p | |
| Hard Disk | ||
| SATA | 4 SATA interfaces for 4 HDDs | |
| Capacity | Up to 8TB for Each Disk | |
| External Interface | ||
| Network Interface | 1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface | |
| Serial Interface | 1 RS-485 (Half-Duplex), 1 RS-232 | |
| USB Interface | Front Panel: 2USB 2.0; Rear Panel: 1USB 3.0 | |
| Alarm In/Out | 16/4 | |
| PoE | ||
| Interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet Interfaces | |
| Max Power | 16RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface | |
| Supported Standard | IEEE 802.3 af/at | |
| General | ||
| Power Supply | 100~240V AC | |
| Consumption | ≤20W (Without Enabling PoE) | |
| Working Temperature | +14F ~ +131 F(-10C ~ +55C) | |
| Working Humidity | 10% - 90% | |
| Casing | 19-Inch Rack-Mounted 1.5U Casing | |
| Dimension | 17.5" 15.3" 2.8"(445 390 70 mm) | |
| Weight | ≤11lb (5Kg) | |
