Eyemax TVST-TE2708-N5 TE Series | 8CH Penta-brid DVR system, H.265, 8MP TVI / AHD / CVI / IP Camera + Analog, 1 × SATA Slot
Sale price
$315.69
Regular price
$410.00
Skip to product information
Eyemax TVST-TE2708-N5 TE Series | 8CH Penta-brid DVR system, H.265, 8MP TVI / AHD / CVI / IP Camera + Analog, 1 × SATA Slot
Sale price
$315.69
Regular price
$410.00
Up to 8MP(4K) TVI / AHD / CVI • Up to 8MP(4K) IP Camera • Standard H.265 high profile compression format • Pentaplex: preview, record, playback, backup and remote access • HDMI 4K output • Remote control via Web Client or CMS • Superlive Plus app available on iOS / Android • 1 × SATA
- 8 CH TVI / AHD / CVI (8MP / 5MP / 4MP / 3MP / 1080P / 720P / WD1) video input
- Support 2 CH 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P IP video input by default
- Adopt standard H.265 high profile compression format to get high-quality video at much lower bit rate
- Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
- Multi-mode recording: manual / timer / motion
- Playback : 8 CH simultaneously playback
- Search: time slice, time, event, tag and smart search
- Express and flexible backup via USB, network and so on
- Pentaplex: preview, record, playback, backup and remote access
- DHCP, DDNS, PPPoE network protocol
- Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration
- Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
- Multi-user online simultaneously Authorization management, log review and device status review
- HDMI 4K output, true high resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises Support NAT function and QRCode scanning by mobile phones
- Powerful mobile surveillance by smart phones with iOS and Android OS
| Video | |
|---|---|
| Analog Video Input | BNC × 8 BNC interface (1.0Vp-p; 75Ω) TVI / AHD / CVI : 4K@15fps, 5MP@20fps, 4MP / 3MP / 1080P / 720P / WD1@30fps (live) |
| IP Video Input | 8CH (up to 16CH) Up to 8MP@30fps |
| Total Input | 16CH |
| Output | HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 BNC × 1 : CVBS ( used as the main or spot output ) |
| Compression | H.264 / H.265 |
| Audio | |
| Input | RCA × 4 |
| Output | RCA × 1 (linear, 600Ω) |
| Two-way audio | Take up channel one audio input |
| Compression | G.711(U/A) |
| Record | |
| Resolution | 4K/4K Lite / 5MP / 5MP Lite / 4MP / 4MP Lite / 3MP / 1080P / 720P / WD1 / D1 |
| Frame Rate (Analog Channel) | 4K@6/7fps (PAL/NTSC) (All channels support) 4K Lite@12fps/15fps (PAL / NTSC) 5MP@12fps (PAL / NTSC) 5MP Lite@20fps (PAL / NTSC) 4MP/3MP@12fps(PAL) / 15fps (NTSC) 4MP Lite / 1080P / 720P / WD1 / D1@25fps (PAL) / 30fps (NTSC) |
| Frame Rate (IP Channel) | 25fps (PAL) / 30fps (NTSC) |
| Bit Rate | 32Kbps ~ 5Mbps |
| Mode | Manual, timer, motion, smart event |
| Playback | |
| Playback | 8CH |
| Search | Time slice / time / event / tag search |
| Smart Search | Highlight colors to display the camera record in a certain period of time, different colors refer to different record events |
| Function | Play, pause, FF, FB, digital zoom, etc. |
| Network | |
| Interface | RJ45 1000Mbps × 1 |
| Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, NTP, SMTP |
| Incoming Bandwidth | 32Mbps (Max.64Mbps) |
| Outgoing Bandwidth | 96Mbps |
| Mobile Device | |
| OS | iOS, Android |
| Storage | |
| HDD | SATA × 1, up to 8TB per HDD |
| Backup | |
| Local Backup | U disk, USB mobile HDD |
| Network Backup | Yes |
| Port | |
| RS 485 | Yes (half-duplex), connect to PTZ or keyboard |
| USB | USB 2.0 × 2 |
| Others | |
| Power Supply | DC12V / 4A |
| Consumption | ≤ 15W ( without HDD )</t |
| Dimensions | 11.81 × 9.45 × 1.77 ( W × D × H) inches 300 × 249 × 45 ( W × D × H )mm |
| Working Environment | ×10 ~ 50°C, 10%~90% (humidity) |
